HY601742 10/100Base-T Voip Magnetics Modules With POE Capability

Name: HY601742 10100BaseT Voip Magnetics Modules With POE Capability
Brand: LINK-PP
Price: 0.06 USD

Brand Name : LINK-PP

Model Number : HY601742

Certification : UL,RoHS,Reach,ISO

Place of Origin : Guangdong,China

MOQ : 400/2000/10K/25K

Price : $0.06-$3.2

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3KK/Month

Delivery Time : Stock

Packaging Details : T&R

Pulse PN : HY601742

Made In China : SM-LP2019ANL

Family : Ethernet POE Transformer

Mounting : Surface Mounting

Pins : 16 Pins

Samples : Free Available

Archivi Disponibili : PDF/3D/ISG/Stp/Step/Datasheet

Contact Now

HY601742 10/100Base-T Voip Magnetics Modules With POE Capability

HY601742 Hanrun

Trader Part Number

HY601742

Price Break	Unit Price	Extended Price
1-5	A	-
10-50	B	-
100-500	C-1	-
1,000-2,500	Supportive	-
5,000	Dynamic	Dynamic
10,000	Dynamic	Dynamic
50,000	Negotiable	Negotiable
100,000	Negotiable	Negotiable
500,000	Negotiable	Negotiable

Made in China

SM-LP2019ANL

Manufacturer

LINK-PP China

Description

Ethernet Transformer Modules

Documents Available

PDF/3D/Step/IGS/Price/Cross

Quantity Available

2,000 PCS or 4 weeks

HY601742 Product Features:

Electrical Specification @25℃
1.Turns Ratio:
TX=1CT:1CT RX=1CT:1CT
2.Insertion Loss:
0.1-100MHz:-1.0dB MAX
3.Return Loss:
0.1-30MHz:-18dB MIN
30-60MHz: -13dB MIN
60-80MHz:-12dB MIN
4.Crosstalk:
0.1-100MHz:-35dB MIN
5.DCMR:
30MHz:-42dB MIN
60MHz:-36dB MIN
100MHz:-33dB MIN
6.CMRR:
1-100MHz: -40dB TYP
7.L: 1-3,6-8:
350uH MIN 100KHz 0.1V 8mADC
8.DCR: 1-3,6-8: 0.9 OHM MAX
9.LK:
1-3(Tie:16+14):0.5uH MAX 100KHz 0.1V
6-8(Tie:11+9): 0.5uH MAX 100KHz 0.1V
10.Cw/w:
(1-3),(16-14):28pF MAX 100KHz 0.1V
(6-8),(11-9): 28pF MAX 100KHz 0.1V
11.Isolation Voltage: 1500Vrms

HY601742 10/100Base-T Voip Magnetics Modules With POE Capability

HY601742 10/100Base-T Voip Magnetics Modules With POE Capability
