J0C-0006NL / LPJ19111CNL SMT Modular Jack 10/100 Filter Integrated Rj45

Name: J0C0006NL LPJ19111CNL SMT Modular Jack 10100 Filter Integrated Rj45
Brand: LINK-PP
Price: 1 USD

Wholesale J0C-0006NL / LPJ19111CNL SMT Modular Jack 10/100 Filter Integrated Rj45 from china suppliers

Brand Name : LINK-PP

Model Number : J0C-0006NL

Certification : ISO9001,SGS,UL,CE,REACH,RoHS

Place of Origin : GuangDong, China

MOQ : 720

Price : Supportive&Discount

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3000000/Month

Delivery Time : Stock

Packaging Details : 120pcs/reel,6Reel=35*35*35cm=9KGS(720pcs)/Carton

Specification : J0C-0006NL

Part No : LPJ19111CNL

Ethernet : 1x10/100Mbps

Indicator : None LEDs

Mounting : SMD

Samples : Available

Contact Now

J0C-0006NL / LPJ19111CNL SMT Modular Jack 10/100 Filter Integrated Rj45

10/100Base-TX surface mount RJ45 single port (1x1) Tab-DOWN Without LEDs Integrated Magnetics Connector
Surface Mount Rj45 Connector Female Jack
Designed to support applications such as: Set Top Box and Network Interface Cards (NIC).
Link-PP LPJ19111CNL SMD Rj-45 Jack Shield Wo/LED Latch-down
Cross Pulse J0C-0006NL Specifications

LINK-PP LPJ19111CNL 100% Cross J0C-0006 / J0C-0006NL / J0C-0006NLT Pulse

SMT RJ45 Female Connector with 10/100 Base-T Integrated Magnetics,Without LED,Tab Down,RoHS
LINK-PP Part Number	LPJ19111CNL
Pulse Part Number	J0C-0006 / J0C-0006NL / J0C-0006NLT
Application-Lan	ETHERNET(NoN PoE)
AutomDX	YES
Bst Circuit	YES
Configuration RX	T,C
Configuration TX	T,C
Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Cores per Port	4
Diodes	NO DIODES
LED Option	WITHOUT LEDS
Latch	TAB DOWN
Number of Ports	1X1
PCB	FR4
PCB Mount Angle	SIDE ENTRY
PCB Retaining Post	T POST
Package Height (Inches)	0.535
Package Height (mm)	13.60
Package Length (Inches)	0.964
Package Length (mm)	21.95
Package Width (Inches)	0.640
Package Width (mm)	16.26
Pin Type	SURFACE MOUNT
RoHS Compliant	YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search	YES
Shield EMI Tabs	WITH
Speed	10/100 BASE-T
Temperature	0 TO + 70℃
Turns Ratio RX	1CT:1CT
Turns Ratio TX	1CT:1CT

J0C-0006NL / LPJ19111CNL SMT Modular Jack 10/100 Filter Integrated Rj45
