ARJ11D-MASH-B-A-ELU2 Networking Rj45 Modular Jack For Central Controller

Brand Name : LINK-PP

Model Number : ARJ11D-MASH-B-A-ELU2

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000/25K

Price : $0.05-$1.28

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 5000K-PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

PN Customer : ARJ11D-MASH-B-A-ELU2

Made In China : LPJXXXXNL

Design Flexible : Yes

Samples : Free Available

Hipot Test : 1500Vrms

Orientation : 90° Angle (Right)

Contact Now

ARJ11D-MASH-B-A-ELU2 Networking Rj45 Modular Jack For Central Controller
ARJ11D-MASH-B-A-ELU2 Networking Rj45 Modular Jack For Central Controller

ELECTRICAL SPECFICATIONS @25℃
1.Turn Ratio(%%P2%):
TX=1CT:1CT RX=1CT:1CT
2.Inductance OCL: 350uH MIN
@ 100KHz/0.1V 8mA DC Bias
3.Insertion Loss:
1-65MHz:-1.0dB MAX
4.Return Loss(dB MIN):
1-10MHz: -20

10-30MHz:-16
30-60MHz: -12

60-80MHz:-10
5.Cross talk(dB MIN):
1-30MHz: -40

30-60MHz: -35
60-100MHz:-30
6.Common Mode Rejection(dB MIN):
1-50MHz: -40

50-150MHz: -35
7.Hipot Test: 1500Vrms
8.Operating Temperature Range: 0℃ TO 70℃

Applications For Terminal User

Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem,Call Center solutions , Complex set top boxes , VOIP gateways setup,Border Gateway Protocol,fast ethernet switch ...

Main Customer

Design for Ti , Intel , Samsung , Fluke , Jabil , Flextronics ,Cypress, Freescale,EKF.......

EMS Application

Built-in Flexible PCB Assembly; Rigid-Flexible PCB Assembly; Microelectronic, Flip Chip; Microelectronic, Chip On Board; Optoelectronic Assembly; RF / Wireless Assembly; Through Hole Assembly; Surface Mount Assembly; System Assembly; Printed Circuit Board Assembly

LINK-PP RJ45 Designed for BeagleBone Black of Texas Instrument
http://www.ti.com/tool/beaglebk#0
a low-cost, open source, community-supported development platform for ARM® Cortex™-A8 processor developers and hobbyists.

LINK-PP ------------ The Appointed Supplier And Supporter Of Embedded System for Ti
ARJ11D-MASH-B-A-ELU2 Networking Rj45 Modular Jack For Central Controller
