Equivalent To 11FC-05GNL 10/100Base-t Magnetic Transformer LP1102NL

Name: Equivalent To 11FC05GNL 10100Baset Magnetic Transformer LP1102NL
Brand: LINK-PP
Price: 0.06 USD

Wholesale Equivalent To 11FC-05GNL 10/100Base-t Magnetic Transformer LP1102NL from china suppliers

Brand Name : LINK-PP

Model Number : 11FC-05GNL (LP1102NL)

Certification : UL,RoHS,Reach,ISO

Place of Origin : Guangdong,China

MOQ : 400/2000/10K/25K

Price : $0.06-$3.2

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3KK/Month

Delivery Time : Stock

Packaging Details : T&R

PN : LP1102NL

Compatible : 11FC-05GNL

Speed : 10/100Base-T

Port : Single

Pins : 16

Hipot : 1500Vrms MIN

Contact Now

Equivalent to 11FC-05GNL 10/100 Magnetic Transformer LP1102NL

Pin to pin 11FC-05GNL

Factory PN

LP1102NL

Price Break	Unit Price	Extended Price
1-5	A-F	-
10-50	B	-
100-500	C-1	-
1,000-2,500	Supportive	-
5,000	Dynamic	Dynamic
10,000	Dynamic	Dynamic
50,000	Negotiable	Negotiable
100,000	Negotiable	Negotiable
500,000	Negotiable	Negotiable

Cross References

Equivalent to 11FC-05GNL

L/T

Stock

Description

SIN Magnetics 10/100 SMT

Documents Available

PDF/3D/Step/IGS/Price/Cross

Quantity Available

500000 pcs

Compatible 11FC-05GNL Electrical Specifications @25℃

1. OCL: 350uH MIN
@100KHz,0.1Vrms,8mADC Bias
2. Turns Ratio:
TX=1CT∶1CT RX=1CT∶1CT
3. Insertion Loss:
0.1-100MHz:-1.1dB MAX
4.Return Loss(dB TYP):
30MHz:-20 60MHz:-14
80MHz:-11.5
5.Crosstalk(dB TYP):
30MHz:-45 60MHz:-40
100MHz:-35
6. DCMR(dB TYP):
30MHz:-42 50MHz:-37
100MHz:-33
7. Hipot: 1500Vrms MIN
8. Operating Temperature: 0℃～70℃./-40℃～85℃

Equivalent To 11FC-05GNL 10/100Base-t Magnetic Transformer LP1102NL
