RJ45 Connector With 1000 Base-T Integrated Magnetics For BeagleBone AI-64

Name: RJ45 Connector With 1000 BaseT Integrated Magnetics For BeagleBone AI64
Brand: LINK-PP
Price: 0.09 USD

Wholesale RJ45 Connector With 1000 Base-T Integrated Magnetics For BeagleBone AI-64 from china suppliers

Brand Name : LINK-PP

Model Number : LPJG0933HENL

Certification : UL,ROHS,REACH,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : $0.09-$3.85

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4200K-PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

Connector Type : Integrated Magnetics RJ45

Speed : 1000 Base-T

Orientation : 90°Angle (Right)

Number of Positions/Contacts : 10P8C (RJ45, Ethernet)

LED Emittng Color : Green,Yellow

Application : Beagle Bone AI-64 Ethernet Connector

Housing Material : Thermplastic PBT+30%G.F UL94V-0

UL Certification : File Numer E484635

Contact Now

RJ45 Connector With 1000 Base-T Integrated Magnetics For BeagleBone AI-64

1000Base-T RJ45 Description

The LPJG0933HENL is LINK-PP's single port RJ45 ethernet connector designed for BeagleBone AI-64. it ensures
reliable data transmission with integrated magnetics. Featuring 10/100/1000 Base-T speed, down latch design, and
gold-plated contacts, this RJ45 Integrated Magnetics provides secure and stable connections.

Features of 1x1 ports 1000Base T RJ45 connector

Meets IEEE802.3 specification.
Integrated magnetics for enhanced signal integrity and EMI protection.
High-speed connectivity with support for 10/100/1000 Base-T Ethernet.
Designed for BeagleBone AI-64 board Application.
Down latch design ensures secure and stable connections.
90° right-angle orientation for space-constrained applications.
Gold-plated contacts for reliable conductivity.
LED options for visual network status indication.

BeagleBone AI-64 RJ45 Connector Specifications

Brand	LINK-PP
Part Number	LPJG0933HENL
Overview	1x1 ports 1000 Base T RJ45 connector 10P8C Modular Jack
Mounting Type	Through Hole
Orientation	90° Right Angle SIDE ENTRY
Speed	10/100/1000 Base-T
Latch	Down
Cores per Port	8
Shield EMI Tabs	Without
Application-Lan	Ethernet (NoN PoE)
Hipot Test	1500Vrms MIN
Insertion Loss	-1.0dB Max @1KHz~100MHz -1.2dB Max @100KHz~125MHz
Inductance OCL	350uH MIN @100KHz/0.1V, 8mA DC Bias
Return Loss	-16dB MIN @1MHz-40MHz -12dB MIN @40MHz-60MHz -10dB MIN @60MHz-80MHz -8dB MIN @80MHz-100MHz
Common to Common Mode Attention	-30dB MIN @1MHz-100MHz
Crosstalk	-30dB MIN @1MHz-100MHz
LPJG0933HENL Length	0.837 inches/21.25 mm
LPJG0933HENL Width	0.627 inches/15.93 mm
LPJG0933HENL Height	0.524 inches/13.30 mm

RJ45 Connector With 1000 Base-T Integrated Magnetics For BeagleBone AI-64

Application for BeagleBone AI-64:

The RJ45 connector with 1000 Base-T is seamless integration with the BeagleBone AI-64. LPJG0933HENL improves the expandability of the BeagleBone platform. it provides a reliable and high-speed Ethernet connection for AI and machine learning.
